The medium high foldable travel trike 26 inch
The Luggage Champion for Your Grand Tour – Scorpion fx 26
More Suspension Travel, More Ground Clearance, More Freedom on the Roads
No mountain too high, no desert too hot, and no long-distance cycling route too challenging? Then unleash the extraordinary Scorpion fx 26 and discover your ultimate three-wheeled adventure companion!
The impressive Scorpion fx 26 delivers performance that speaks volumes. With a remarkable 150 kg (331 lbs) payload capacity – 10 kg (22 lbs) more than the Scorpion fx 20 and most other Scorpion models– you’ll have the freedom to pack everything your adventure demands.
Experience grand comfort with a total of 10 cm (4″) of super plush suspension at the rear wheel – our engineers have added an extra 15 mm (0.6″) of suspension travel. And with 25 mm (1″) additional ground clearance, rough trails become just another reason to smile.
Add to this the large 26-inch rear wheel as your flywheel. Feel firsthand what cycling enthusiasts mean by “length runs”: superior smoothness while the large rear wheel effortlessly conquers roots and potholes. Simply ride relaxed!
Great performance – small pack size. As assertive as your trike is on your tours, it remains just as manageable before and after your ride. It gladly fits in the trunk of most cars thanks to HP Velotechnik’s ingenious Flat fold with self locking hinge. The design allows the rear frame and wheel to rotate almost 90 degrees when folded. For long-distance transport, you can make the Scorpion fx 26 even more compact with just a few simple steps. Call your local dealer today to arrange a personal demonstration and test ride to experience these benefits and more!
Zum Vergrößern klicken
Scorpion fx 26 With Flat Fold Technology
Unfold Pure Riding Pleasure!
Experience the Scorpion fx 26‘s sophisticated folding technology! Thanks to HP Velotechnik’s ingenious Flat fold with self locking hinge, this premium trike with its impressive large rear wheel transforms into a travel-ready companion in just seconds. The design allows the rear frame and wheel to rotate almost 90 degrees when folded.
In just a few simple steps, your Scorpion fx 26 compacts into an incredibly space-efficient package measuring just 111 x 83 x 66 cm. Want even more portability? Remove the frontwheels and the trikefenders and watch it shrink to an astonishing 93 x 74 x 54 cm! Even with all your accessories – luggage rack and fenders included – the folding magic happens without removing a single wheel. And forget chain worries! Our sophisticated chain management system with flexible guard tubes ensures perfect positioning every time.
Here’s the game-changer: HP Velotechnik’s innovative self-locking folding hinge means you’ll easily go from compact transport mode to exhilarating ride set-up. As the frame stays in position after unfolding, you can conveniently close the safety latch with one hand. Turn your trike riding dreams into reality with the ultimate blend of comfort, style and performance!
Top Virtues of the Scorpion fx 26
Globetrotter with a Panoramic View
Scorpion fx 26. The Comfortable, Foldable Travel Trike.
The streamlined, relaxed seating position on the Scorpion fx 26, just like on a recumbent trike, ensures a fast pace. The seat angle is widely adjustable. The seat height of at least 35 cm (14″) was chosen by HP Velotechnik for the Scorpion fx touring trikes to be significantly higher than the sportier Scorpion to provide a very good overview in road traffic. The rearward curved frame cross member allows the driver to get close to the seat and get on and off without effort. And even when stopping at traffic lights, the driver no longer has to take his feet off the pedals positioned at the height of 38-46 cm (15-18″) but can accelerate powerfully from the comfortable recumbent seat.
The frame suspension with 10 cm (4″) travel works unaffected by pedaling forces thanks to HP Velotechnik’s proven No Squat design. The stiff aluminum frame allows a very low weight for 26 inch tricycles from 17.2 kg (37.9 lbs). The frame and seat are adjustable in length to suit riders from 1.57 m to 2.00 m (5’2″– 6’7″) tall. The frame and seat are adjustable in length to suit riders from 1.57 m to 2.00 m (5’2″– 6’7″) tall.
Wider is better: The wider the track, the greater the tipping stability and the faster your recumbent trike can corner. A wide track also allows a bigger steering angle for a small turning circle. So that your Scorpion fx still fits easily through doors and gates, HP Velotechnik has developed narrow hubs for a low overall width of just 83 cm (33″). (You want it even wider? The maximum track width and the highest seating position of our Tadpole trikes can be found with the models Scorpion plus 20 and Scorpion plus 26.)
Custom CSS for Advanced Carousel - Do not delete
The Details at a Glance
Your foldable travel trike Scorpion fx 26 has these technical refinements on board as standard.
Ergonomic Handlebars
Comfortably positioned ergo-bars beneath the seat. Your wrists and neck are relieved from strain. HP Velotechnik's steering geometry combines smooth straight-line stability with impressive maneuverability. Maintenance-free, sealed cartridge bearings on the handlebars and self-lubricating rod end bearings on the tie rods. The wheel mounts are positioned in the frame with sturdy, adjustable A-head headsets. The handlebars are adjustable in width and angle.
Robust Folding Hinge
On unfolding the trike, the robust HP Velotechnik folding hinge locks into place automatically. The safety catch can be conveniently operated from above. Stainless steel axle with zero play for precise folding over and over again.
Disc Brakes
The Scorpion fx 26 has a very safe braking action due to the low center of gravity and the long wheelbase. The standard disc brakes ensure maximum braking power even in bad weather. The front wheels are controlled separately so that you can selectively brake the inner wheel when cornering. Due to HP Velotechnik's sophisticated steering geometry, the steering is not affected by braking or sudden bumps on your trail. On request, we build your trike with mechanically or hydraulically coupled front brakes with one-hand operation and a rear disc brake.
Chain Protection Tubes
Protects your clothes and the chain: The drive train is mostly covered. The unique chain tubes made from durable plastic create minimum friction for a quiet ride. The frame is adjusted to your leg length by shortening or extending the front boom in the main frame.
Easy wheel removal
Easy to transport: HP Velotechnik has developed open wheel mounts that allow the front wheels to be easily detached together with the brake disc by loosening just one bolt (HP Performance hubs are standard on Scorpions).
Suspension
HP Velotechnik’s adjustable suspension provides superior ride comfort on your fast electric bike. The suspension utilizes HP Velotechnik’s tried-and-tested No-Squat suspension concept. It reliably prevents drive forces from affecting the suspension and unpleasant pedal kickback. This enables you to accelerate at all times powerfully. If desired, your Scorpion fx 26 can be equipped with the lightweight air suspension element from RockShox (picture). The spring stiffness can be easily adjusted to the payload using a shock pump. Equipped with adjustable hydraulic rebound damping and a block-able compression stage, it boasts the best response recorded in our tests.
Accessories
Optional Features for True Individuals
Do you have your own notion of your ideal trike technology? Our modular system enables us to build your recumbent tricycle to meet your needs and desires. A whole range of reliable features and components is available for your compact folding recumbent trike, all of which have been specially developed to excel in everyday use Here we show some selected examples; you will find the complete selection in our price lists and catalogs as well as our online configurator.
BodyLink-Seat
The HP Velotechnik seat systems provide an exemplary ergonomic connection at the key interface between the rider and the trike. With the adjustable BodyLinkhard shell seat, the lower seat shell offers excellent side support, while the upper seatback gives enough freedom for you to lean dynamically into the curve when cornering. Waterproof seat pad cushion made of EVA foam or breathable Airflow seat cushion (multi-layer system).
ErgoMesh Premium seat
The ErgoMesh Premium mesh seat gives you the most flexible seat comfort you can imagine.The seat bottom part and backrest can be adjusted independently of each other, the seat cover can be adjusted using the eight tensioning straps.There are also four additional Othoflex support cushions inside the seat cover that you can cut to size and position to suit your individual shape.
Rear Rack
Your luggage will be carried with full suspension. This enables agile driving dynamics and helps to protect your equipment. The stable rack for loads of up to 25 kg (55 lbs) has been optimized to withstand the high lateral forces while riding your trike. The robust construction with 14 mm tubes allows you to hang your panniers with a low center of gravity. It also has a well-integrated flagpole mount for added safety in traffic.
Lowrider
In addition, our Lowrider carrier can be mounted on the Scorpion fx 26's luggage rack. It can also carry up to 25 kg. Tube diameter 10 mm.
Top Load Rack
For additional luggage space, supplement the luggage rack with the Top Load platform, which bolts onto the rack. This allows you to carry bulky or voluminous items such as a sleeping mat or tent on your trike while using your rack and Lowrider for your heavier panniers.
Fenders / Mudguards
Functional fenders: The HP Velotechnik trike fenders offer excellent rider protection against spray from the rear and in particular, from the side. HP Velotechnik enlarged the inside facing part to improve the spray protection to the driver, especially when cornering. Elegant mounting hardware located on the inside of the fender with height adjustment. The rounded shape of the fenders with 60 mm / 2.36" width allows the installation of large-volume, comfortable tires up to 50 mm / 2" width.
Parking Brake
As a parking brake, we can install a V-brake on the rear wheel. It is operated by a thumb lever at the handlebar.
front boom quickadjust
The optional quick frame adjustment with quick-release levers can be used to adapt the bike to different leg lengths quickly. By pushing in the front boom, your Scorpion fx 26 becomes more compact for transport.
Weather Protection Gear
The Streamer front fairing from HP Velotechnik keeps your feet warm and legs dry. The fairing can be easily removed using the quick-release lever and rolled up for transport.
Electric Power-Assist
Do you offer electric drive assistance? Certainly, we do – this is another domain of our trikes! HP Velotechnik can optionally equip all vehicles with a powerful electric motor. No other type of bicycle fits electric motors as perfectly as recumbent trikes. Why is obvious: The ease of pedaling and the ergonomic sitting position make the ride even more pleasant. The built-in aerodynamic advantage of your recumbent trike can also be exploited electrically: less drag means more range. And as a special highlight, you can even equip your trike with a second battery for twice the range!
Build My Dream Bike Now!
Fast, convenient, and informative: Selecting the components of your foldable touring trike is easy with our online configurator. Choose to your heart’s content from our versatile modular system!
Facts and Figures
Specifications and Technical Data Scorpion fx 26
The outstanding ride of our foldable travel trike is of course based on thoroughly engineered performance technology with precise technical specifications. The detailed figures can be found here in the technical data sheet – from the dimensions to the payload, from the seat height to the appropriate rider size. And of course, we are also happy to show you which colors you can choose for your Scorpion fx 26.
- Wheel size front: 20″ (ISO 406)
- Wheel size rear: 26″ (ISO 559)
- Max. tire width: 5 cm (2″)
- Bottom bracket height: 38–46 cm (15″– 18″)
- Ground clearance: 16 cm / 6.3″ (statically compressed)
- Wheelbase: 120 cm (47″)
- Track width: 78 cm (31″)
- Width: 83 cm (33″)
- Length: 190–221 cm (6’2″–7’3″)
- Turning circle: 5,20 m (17′) outer wheel
- Folding size: 111 × 83 × 66 cm
- Dismantled size: 108 × 74 × 56 cm
Standard color: Pearl orange
Standard color: Cool grey metallic / swing arm Black
- Bottom bracket standard: BSA 68 mm
- Suspension travel (rear): 10 cm
- Weight: from 17,2 kg (37.9 lbs) incl. pedals
- Payload: max. 150 kg (330 lbs)
- Frame material: Aluminum 7005 T6 heat treated
- Swing arm bearing: maintenance-free
- Rider height: ca. 1,57 – 2,00 m (5’2″– 6’7″)
We are committed to the quality of our products. Therefore we grant a guarantee of 10 years on the frame and the swing arm bearing of our bikes and trikes. For further information, please have a look at our warranty conditions.
They Even Have a catalog? This Is Getting Better and Better!
You will find all the details about the Scorpion fx 26 folding recumbent touring trike in our detailed and richly illustrated Scorpion tricycle catalog. Also, you will read lots of background information about tricycles for adults and fascinating reports about trike tours all over the world.
Even now you have the choice with us: Browse here online on our website. Or request your copy in high-quality printing form by post. So you can comfortably recline at home on your sofa and start discovering the world of recumbent bicycles – without obligation and completely free of charge.
Do you want to read more?
They Even Have a catalog? This Is Getting Better and Better!
In our detailed Scorpion tricycle catalog you will read all the details about the folding recumbent tricycle Scorpion fx 26 and exciting adventures of cycling tours by trike all over the world.
Request your copy in a high-quality printing form right away. So you can comfortably recline at home on your sofa and start discovering the world of recumbent bicycles – without obligation and completely free of charge.
FAQ
Scorpion fx 26 Frequently Asked Questions
The characteristics of our trikes depend on many factors. The wheel size is only one. HP Velotechnik optimized the geometry of each model for specific characteristics (with or without full suspension, foldable or not foldable, small rear wheel or large rear wheel, etc.). A conversion in this area would have a negative effect on the overall balanced system and thus on the riding characteristics – therefore our trikes are not intended for such a conversion.
In our concept, the specialist trade is the central sales pillar. Our selected and trained specialist dealers can advise you in detail. Above all, however, they offer a promptly available service locally, which we cannot provide within the framework of our manufactory with some production processes planned for the long term. For these reasons we also do not sell directly to the customer at the factory.
A lot works with a lot – but not everything is compatible with everything. This is obvious with some combinations: a hub gear plus a hub motor in the same rear wheel is not possible. The easiest way to choose your specifications: Enter your whishes in our online configurator – we’ve programmed it with all possible combinations, compatibility, and descriptions on our component choices. For detailed advice on choosing the best option for your desired application, please contact your specialist dealer.
System weight means the weight of rider + luggage + bike (if applicable incl. motor). The payload refers to driver + luggage. In practical terms, this means that if you install an engine in your Scorpion fx 26, you have to subtract its weight from the possible payload.
You can carry up to 8 bags plus another piece of luggage on the platform above the rear wheel:
On the luggage rack specially designed for our 26 inch trikes, you can store two standard bags (e.g. Ortlieb Backroller). When fitted with the Top Load attachment, an additional piece of luggage can be stored on the platform.
With the Lowrider carrier you bring two more panniers to your bike.
If you choose the ErgoMesh or ErgoMesh Premium seat and our matching Side bag mounts, you have easy access to an additional 10 kg of luggage in two handlebar bags next to the seat. There is also a choice of two additional bags for attaching to the backrest for these mesh seats (Add-on bags).
Picture Gallery
Here You Can Enjoy the Best Views
You will experience the best reasons for one of our recumbents during an extended test ride. On our website, we can only describe to you the incomparable driving feeling. True to the saying “A picture says more than 1000 words” we want to let our Scorpion fx 26 recumbent travel trike speak for itself.
Move the mouse pointer over the image. Use the magnifying glass symbol to open the picture gallery. Alternatively, you can use the link icon to download photos in high resolution, e.g., as a desktop background – simply right-click after opening the image. You can find more high-resolution pictures in our album about Scorpion fx 26 on Google Photos.
