Trike Dynamics Comfortably Balanced: Scorpion fs 20

Discover HP Velotechnik's Compact Full-Suspension Foldable Touring Trike

It’s good to know, that even if things get rough ahead of you, you can still stay laid back and relaxed. When developing the award-winning design of the Scorpion fs 20 foldable touring trike, HP Velotechnik’s engineers used the latest chassis technology from the automotive sector to provide the most comfortable full suspension for your ride. But they did not compromise by simply using retro-fit solutions on existing frames:

The whole vehicle was developed from scratch to incorporate an impressively sensitive full suspension in a sleek and lean design delivering superior performance. The wishbone axle geometry and HP Velotechnik’s unique Stabilizer System, with its anti-roll bar integrated into the frame design allow full use of the ample suspension travel. It is finely tuned to perfectly respond to the forces of the road. The low seat and far higher pedal position highlight the agile adult trike’s sporty character.

You can feel the benefits of this masterpiece of finest German trike engineering immediately when cutting your first corner: enjoy a perfect synthesis of outstanding road-holding and a maximum of “Fahrvergnügen.”

The Full Suspension Chassis

The Roughest Road Becomes an Exhilarating Ride

Potholes, cobblestones, gravel roads: the condition of your way ahead can be shocking indeed. From now on, you are going to look forward to riding those sweet little challenges. Once you want to leave the beaten track, you need a quick responding suspension, stable road holding, precise steering, and an optimum of steadiness. Now, the Scorpion fs 20 is your perfect choice.

The comfortable MacPherson front suspension has 6 cm (2.4 inches) of travel and uses a reliable spring and elastomer system. The suspension struts are supported on the far end of the frame’s rigid, large-diameter crossbar close to the wheel. The adjustable wishbones are equipped with maintenance-free bearings.

With this design, our engineers were able to keep unsuspended masses at a minimum, achieving a rapidly responding front suspension action with an astonishingly low weight from 17,5 kg for the fully suspended recumbent touring trike Scorpion fs 20. The suspension preload is adjustable. By exchanging the steel springs and varying the parallelly positioned MCU-elastomer / spacer stack, you can adjust the suspension characteristics, stiffness, and progression to match your personal riding style and needs.

The Scorpion fs 20’s most unique feature is the beefy wishbone and stabilizer bar system under the cruciform frame. This stops the trike from rolling in corners while preserving its suspension movement. Control at the extreme limits is noticeably improved and tipping safety significantly increased. The AntiDive kinematics prevent the negative dive effects on braking.

The design of the camber and track geometry ensures that the steering mechanism offers straight-line stability over the entire suspension travel and remains easily accessible and free from impairment when braking (brake steer) or traversing obstacles (bump steer). You can feel it immediately: in the precision of the steering, the sporty handling, and the direct feedback from the road.

The entire chassis is designed using our No Squat suspension design and transmits all of your drive energy to the road without any loss of power. In return, you enjoy complete comfort so that you can lean back and relax while dynamically accelerating, even on rocky roads.

Top Virtues of the Scorpion fs 20

Sportiness
0%
Comfort
0%
Travel suitability
0%
Everyday strength
0%
Transportability
0%

Aluminum knuckles

Sandblasted and matt anodized surface Ball head of the track rod protected against splash water

liegedreirad trike scorpion fs 20 vorderradnabe

Smooth running hubs

Fast wheel removal with our open knuckle system

Large diameter chain idler

Replaceable ball bearings Integrated chain guide.

Precision can be measured, passion for detail must be felt

faltbares dreirad trike scorpion fs 20 faltgelenk

High precision folding hinge

with self-locking latch

eurobike award 2008: Recumbent trike Scorpion fs 20
Unfolds Pure Driving Pleasure

Immense Traction, Precise Tracking, and Minimal Floor Space: Scorpion fs 20

The Scorpion fs 20 received the Eurobike Award for groundbreaking design and above-average product quality. The jury of “iF International Design Forum,” comprised of design experts, specialist journalists and sports scientists, rated amongst others: efficiency, ergonomics, practical value, weight, safety, environmental impact aspects, and finish.

For convenient transport, you can easily fold your Scorpion fs 20 within 60 seconds into a package of 112 × 83 × 63 cm length x height x width (44″ x 33″ x 25″, with installed rear rack). After the easy removal of the front fenders and front wheels, the package reduces to only 112 × 74 × 46 cm (44″ x 29″ x 18″); without the rear rack, the length is almost less than 90 cm (36″). For easy carrying around, your Scorpion fs 20 is fixated in its folded position by a frame-side-mounted adjustable snap-in device that safely secures the folded frame.

The best part: When you unfold the trike, HP Velotechnik’s unique, self-locking folding hinge enables you to turn your excited anticipation into pure riding pleasure quickly!

recumbent trike scorpion fs 20 folded unfolded

Custom CSS for Advanced Carousel - Do not delete

The Details at a Glance

Your Scorpion fs 20 has these technical refinements on board as standard.

Accessories

Optional Features for True Individuals

Have you got your own notion of your ideal bike technology? Our modular system enables us to build your Scorpion fs 20 to meet your needs and desires. A whole range of reliable features and components is available for your recumbent trike, all of which have been specially developed to excel in everyday use. Here we show some selected examples; you will find the complete selection in our price lists and catalogs as well as our online configurator.

fs26videodummy

Build My Dream Bike Now!

Fast, convenient, and informative: Selecting the components of your trike is easy with our online configurator. With your configuration number, you can edit your saved component choice, print and call your dealer for advice.

Facts and Figures

Specifications and Technical Data

The outstanding ride of the full suspension adult trike is the result of thoroughly engineered performance technology with precise technical specifications. The detailed figures can be found here in the technical data sheet – from the dimensions to the payload, from the seat height to the appropriate rider size. And of course, we are also happy to show you which colors you can choose for your Scorpion fs 20 trike.

  • Seat
  • Wheels & Tires
  • Vehicle measurements
  • Colors
  • Miscellaneous
  • Warranty
  • Seat hight BodyLink: 29 cm (12")
  • Seat height ErgoMesh: 32 cm (13")
  • Seat height ErgoMesh HS plus: 43 cm (17")
  • Seat angle: 41–49° adjustable
  • Seat angle ErgoMesh HS: 41–54° adjustable
  • Wheel size (front wheel): 20" (ISO 406)
  • Wheel size (rear wheel): 26" (ISO 559)
  • Max. tire width: 5 cm (2")
  • Bottom bracket height: 40–45 cm (16–18")
  • Ground clearance: 12 cm (5", statically compressed)
  • Wheelbase: 128 cm (44")
  • Track width: 78 cm (31")
  • Width: 83 cm (33")
  • Length: 172–206 cm (68–81")
  • Turning circle: 4.76 m (15.6') outward
  • Folded size:
    90 × 83 × 63 cm (36 x 33 x 25", without rear rack)
  • Dismantled size: 90 × 74 × 46 cm (36 x 29 x 18")
liegedreirad trike vollgefedert und faltbar scorpion fs 20
Standardfarbe: Rapsgelb RAL 1021
full suspension folding recumbent trike scorpion fs 20
Standardfarbe: Blue shade grey matt

Verleihen Sie Ihrem Rad eine persönliche Note: Auf Wunsch können Sie den Rahmen Ihres HP Velotechnik-Liegerades auch mit einer Sonderfarbe ganz nach Ihrem persönlichen Geschmack pulverbeschichten lassen. Sie haben dabei die Auswahl aus hunderten von Farbtönen.

Eine Übersicht und weitere Informationen zu unseren Sonderfarben finden Sie in unserer Farbtabelle.

  • Bottom bracket standard: BSA 68 mm
  • Suspension travel: front 6 cm (2.4") / rear 8 cm (3.1")
  • Weight: from 17.5 kg (39 lbs) incl. pedals
  • Payload: max. 130 kg (286 lbs)
  • Frame material: Aluminum 7005 T6 heat treated
  • Swing arm bearing: maintenance-free
  • Rider height: ca. 1.62 – 2.00 m (5'4" – 6'7")

We are committed to the quality of our products. Therefore we grant a guarantee of 10 years on the frame and the swing arm bearing of our bikes and trikes. For further information, please have a look at our warranty conditions.

They Even Have a catalog? This Is Getting Better and Better!

You will find all the details about the Scorpion fs 20 in our detailed and richly illustrated Scorpion tricycle catalog. Also, you will read lots of background information about tricycles for adults and fascinating reports about trike tours all over the world.

Even now you have the choice with us: Browse here online on our website. Or request your copy in high-quality printing form by post. So you can comfortably recline at home on your sofa and start discovering the world of recumbents – without obligation and completely free of charge.

Do you want to read more?

They Even Have a catalog? This Is Getting Better and Better!

In our detailed Scorpion tricycle catalog, you can read all the details about the fast tricycle for adults and exciting adventures of riders on a trike.

Request your copy in a high-quality printing form right away. So you can comfortably recline at home on your sofa and start discovering the world of recumbents – without obligation and completely free of charge.

FAQ

Scorpion fs 20 Frequently Asked Questions

full suspension trike scorpion fs 20 with bicycle bags panniers

The characteristics of our trikes depend on many factors. The wheel size is only one. HP Velotechnik optimized the geometry of each model for specific characteristics (with or without full suspension, foldable or not foldable, small rear wheel or large rear wheel, etc.). A conversion in this area would harm the overall balanced system and thus on the driving characteristics – therefore our trikes are not intended for such a conversion.

In our concept, the specialist trade is the central sales pillar. Our selected and trained specialist dealers can advise you in detail. Above all, however, they offer a promptly available service locally, which we cannot provide within the framework of our manufactory with some production processes planned for the long term. For these reasons we also do not sell directly to the customer at the factory.

A lot works with a lot – but not everything is compatible with everything. This is obvious with some combinations: a hub gear plus a hub motor in the same rear wheel is not possible. The easiest way to choose your specifications: Enter your whishes in our online configurator – we’ve programmed it with all possible combinations, compatibility, and descriptions on our component choices. For detailed advice on choosing the best option for your desired application, please contact your specialist dealer.

System weight means the weight of rider + luggage + bike (if applicable incl. motor). The payload refers to driver + luggage. In practical terms, this means that if you chose a motor for your Scorpion fs 20, you have to subtract its weight from the possible payload.

The Scorpion fs 20 is designed as a sporty and thus low trike. In addition, the suspension decreases ground clearance. For this reason, a special recumbent bike bag (banana shape) can be used as an option for large quantities of luggage for space reasons and not an additional lowrider.

If you choose the ErgoMesh seat and our matching Side Bag Mounts, you have easy access to another 10 kg of luggage in two handlebar bags next to the seat.
