The mountain trike for off-road trails
Profile
- Comfortable full suspension with AntiDive geometry and Stabilizer system
- Foldable in 60 seconds
- Medium seat height, flat seat position
- Various seats to choose from
- High pedal position for efficient use of pedaling forces
- Good ground clearance
- Very good riding dynamics
- Excellent tipping stability
- 26-inch rear wheel for a smooth ride
- Luggage: up to 35 kg (77 lbs) in seven bags
- Maximum payload 110 kg (243 lbs, off-road), 140 kg (310 lbs, on road)
Mountain-Triking at Its Best!
Scorpion fs 26 Enduro: Automotive Chassis Suspension for Impressive Off-Road Experience
With the Scorpion fs Enduro, HP Velotechnik paves new ways, in the true sense of the word: the trike with chassis technology derived from automotive engineering, MacPherson suspension struts and stabilizing anti-roll bar turns off-road trails into action loaded playground for the adrenaline addicted speedfan.
Based on the proven chassis of the Scorpion fs 26 the Enduro trike has been configured with carefully chosen components. The blue platform pedals turn your leg power into direct propulsion. For even more power, you can optionally mount the extra rigid GX cranks by Sram. Off road the load capacity is at 110 kg (243 lbs), on the road the trike, weighing in from 20,5 kg (45 lbs) will take up to 140 kg (310 lbs).
Rough rider
Massive Grip and Electric Assist on Option
Tough offroad tires with especially strong snake bite protection deliver good grip. (Schwalbe Smart Sam: front 20″ x 2.35″, rear 26″ x 2,1″). With these big knobby tires there is no point in adding fenders. Off road the load capacity is at 110 kg (243 lbs), on the road the Enduro trike, weighing in from 20,5 kg (45 lbs) will take up to 140 kg (310 lbs).
BIKE test director Christoph Listmann in test drive report in BIKE 02-14.
Enduro goes e-trike. Like all other models in the HP Velotechnik range the Scorpion fs Enduro can also be equipped with the powerful Pedelec-System from Neodrives or Shimano STEPS.
Through the electric motor support of up to 25 km/h (16 mph, 20 mph for USA-version) it’s not only that steep climbs become less daunting. With the Scorpion fs 26 Enduro as an e-trike, it’s easy to take your partner on the trails, even if differences in exercise level or riding experience were an issue before. Moreover, the exciting world of mountain biking becomes accessible to a much wider audience: people with special needs, veterans or injured people can now experience exciting outdoor activities off-road from the comfortable seat of HP Velotechnik’s stable Enduro trike and get some extra support from the powerful motor whenever they want to! For extra long trips, the second battery option from HP Velotechnik instantly doubles the maximum range.
Unfolds Pure Driving Pleasure
Comfortable Off-Road and in Transport
With the Scorpion fs 26, HP Velotechnik presented its first full-suspension speed trike with a smooth-running 26-inch rear wheel, that can be folded flat for transport without the use of tools. With the Scorpion fs 26 Enduro, the expert designers at trike specialist HP Velotechnik added another dimension: superb ride comfort inspired by automotive engineering to cope with all the obstacles that off-road riding can offer.
All the outstanding features of the Scorpion series can be found on the Scorpion fs 26 Enduro as well: in just a few simple steps, it only takes a minute for you to fold up your Scorpion fs 26 Enduro into a space-saving package with dimensions of 123 × 83 × 62 cm (49 x 33 x 25″). If you remove the wheels as well, the dimensions reduce even further to a compact 93 × 74 × 54 cm (37 x 29 x 22″). Even with the optional luggage rack attached, the offroad recumbent mountain trike can still be folded up without removing the wheels. And forget chain worries! Our sophisticated chain management system with flexible guard tubes ensures perfect positioning every time.
The best part: When you unfold the trike, HP Velotechnik’s unique, self-locking folding hinge enables you to turn your excited anticipation into pure riding pleasure quickly!
Custom CSS for Advanced Carousel - Do not delete
The Details at a Glance
Your Scorpion fs 26 Enduro off-road recumbent trike has these technical refinements on board as standard.
Ergonomic Handlebars
Robust Folding Hinge
Chain Protection Tubes
Suspension
Disc Brakes
Easy wheel removal
Accessories
Optional Features for True Individuals
Do you have your own notion of your ideal trike technology? Our modular system enables us to build your recumbent tricycle to meet your needs and desires. A whole range of reliable features and components is available for your offroad recumbent mountain trike, all of which have been specially developed to excel in everyday use. Here we show some selected examples; you will find the complete selection in our price lists and catalogs as well as our online configurator.
BodyLink-Seat
The HP Velotechnik seat systems provide an exemplary ergonomic connection at the key interface between the rider and the trike. With the adjustable BodyLinkhard shell seat, the lower seat shell offers excellent side support, while the upper seatback gives enough freedom for you to lean dynamically into the curve when cornering. Waterproof seat pad cushion made of EVA foam or breathable Airflow seat cushion (multi-layer system).
SeatWings
The SeatWings mounted on the lower part of the BodyLink seat will give your body even more support when cornering dynamically. If you think on key, spare tubes or your wallet while riding the attachable MicroBag for the BodyLink seat will be a handy accessory. The MicroBag is attached with velcro straps and can be taken off to double as a convenient hip bag. (Note: use limited with the Scorpion fs 26 Enduro) The MicroBag is attached with velcro straps and can be taken off to double as a convenient hip bag.
ErgoMesh-Seat
The airy ErgoMesh seat is available in several widths and heights. It has anatomically-shaped side cushioning for extra support when cornering and a practical zipper pocket in the backrest. Safety plus: Reflective strips on the seat sides. Both seat systems fit the same frame mounts and are thus interchangeable. They can also be removed entirely in 15 seconds a practical feature when it is raining, or you want to put your recumbent bicycle into your car. The ErgoMesh seat gives you a 3 cm higher sitting position than the BodyLink seat. A higher seating position facilitates boarding and disembarking and improves the overview in traffic, but reduces the tilt stability when cornering at higher speed – please test your desired seat/handlebar combination at your specialist dealer.
Rear Rack
Fancy luggage transport even on rough routes? No problem with your off-road Scorpion. We can install the sturdy rear rack that we developed especially for the Scorpion fs 26 series – and your luggage will be safe and fully suspended on your trails. This enables agile driving dynamics and helps to protect your equipment. The stable rack (14 mm tube) for 2 panniers weighing up to 25 kg (55 lbs) in total has been optimized to withstand the high lateral forces to which trikes are subjected. It comes with a secondary, lowered level to hang your panniers with a low center of gravity. Low sidebars provide secure support for bags. With our Top load attachment you can extend the rack with a platform for light luggage.
Parking Brake
As a parking brake, we can install a V-brake on the rear wheel. It is operated by a thumb lever at the handlebar.
front boom quickadjust
The optional quick frame adjustment with quick-release levers can be used to adapt the bike to different leg lengths quickly. By pushing in the boom tube, you can also make your Scorpion fs 26 Enduro even more compact for transport.
Electric Power-Assist
Enduro Goes E-Trike. Like all models from HP Velotechnik, the Scorpion fs 26 Enduro can also be equipped with a powerful and efficient electric assist system on request: either the GO SwissDrive hub motor or the STEPS drive from Shimano. Through the electric motor support of up to 25 km/h (16 mph, 20 mph for USA-version) it's not only that steep climbs become less daunting. With the Scorpion fs 26 Enduro as an e-trike, it's easy to take your partner on the trails, even if differences in exercise level or riding experience were an issue before. Moreover, the exciting world of mountain biking becomes accessible to a much wider audience: people with special needs, veterans or injured people can now experience exciting outdoor activities off-road from the comfortable seat of HP Velotechnik's stable Enduro trike and get some extra support from the powerful motor whenever they want to! For extra long trips, the second battery option from HP Velotechnik instantly doubles the maximum range.
Build My Dream Bike Now!
Fast, convenient, and informative: Selecting the components of your off road recumbent trike is easy with our online configurator. Choose to your heart’s content from our versatile modular system!
Facts and Figures
Technical Specifications of the Scorpion fs 26 Enduro
The outstanding ride of our off-road trike Scorpion 26 Enduro is the result of thoroughly engineered performance technology with precise technical specifications. The detailed figures can be found here in the technical data sheet – from the dimensions to the payload, from the seat height to the appropriate rider size. Don’t you think green is beautiful? All right, here we’ll show you which custom colors you can choose for your Scorpion fs 26 Enduro.
- Wheel size (front wheel): 20″ (ISO 406)
- Wheel size (rear wheel): 26″ (ISO 559)
- Max. tire width: 54 mm / 2.1″
- Bottom bracket height: 40–45 cm (16–18″)
- Ground clearance: 12 cm (5″, statically compressed)
- Wheelbase: 128 cm (51″)
- Track width: 78 cm (31″)
- Width: 83 cm (33″)
- Length: 187–231 cm (74–91″)
- Turning circle: 5.51 m (18′) outward
- Folded size: 123 × 83 × 62 cm (49 x 33 x 25″)
- Dismantled size: 93 × 74 × 54 cm (37 x 29 x 22″)
Standard color: Green metallic / swing arm Black
Give your bike a personal touch: On request, you can have the frame of your HP Velotechnik recumbent bike powder-coated with a custom color completely to your personal taste. You can choose from hundreds of color shades:
An overview and further information about our custom colors can be found in our color chart.
- Bottom bracket standard: BSA 68 mm
- Suspension travel: front 6 cm (2.4″) / rear 8 cm (3.1″)
- Weight: from 20.5 kg (45 lbs) incl. pedals
- Payload: max.110 kg (242 lbs) off-road, max 309 lbs on-road
- Frame material: Aluminum 7005 T6 heat treated
- Swing arm bearing: maintenance-free
- Rider height: ca. 1.62 – 2.00 m (5’4″ – 6’7″)
We are committed to the quality of our products. Therefore we grant a guarantee of 10 years on the frame and the swing arm bearing of our bikes and trikes. For further information, please have a look at our warranty conditions.
They Even Have a catalog? This Is Getting Better and Better!
You will find all the details about the Scorpion fs 26 Enduro off-road trike in our detailed and richly illustrated Scorpion tricycle catalog. Also, you will read lots of background information about tricycles for adults and fascinating reports about trike tours all over the world.
Even now you have the choice with us: Browse here online on our website. Or request your copy in high-quality printing form by post. So you can comfortably recline at home on your sofa and start discovering the world of recumbent bicycles – without obligation and completely free of charge.
Do you want to read more?
They Even Have a catalog? This Is Getting Better and Better!
In our detailed Scorpion tricycle catalog, you can read all the details about the Scorpion fs 26 Enduro trike and exciting adventures of riders on a trike.
Request your copy in a high-quality printing form right away. So you can comfortably recline at home on your sofa and start discovering the world of recumbent bicycles – without obligation and completely free of charge.
Picture Gallery
Here You Can Enjoy the Best Views
You will experience the best reasons for one of our recumbents during an extended test ride. On our website, we can only describe to you the incomparable driving feeling. True to the saying “A picture says more than 1000 words” we want to let our offroad recumbent mountain trike Scorpion fs 26 Enduro speak for itself.
Move the mouse pointer over the image. Use the magnifying glass symbol to open the picture gallery. Alternatively, you can use the link icon to download photos in high resolution, e.g., as a desktop background – simply right-click after opening the image. You can find more high-resolution pictures in our album about Scorpion fs 26 Enduro on Google Photos.
FAQ
Scorpion fs 26 Enduro Frequently Asked Questions
The characteristics of our trikes depend on many factors. The wheel size is only one. HP Velotechnik optimized the geometry of each model for specific characteristics (with or without full suspension, foldable or not foldable, small rear wheel or large rear wheel, etc.). A conversion in this area would harm the overall balanced system and thus on the driving characteristics – therefore our trikes are not intended for such a conversion.
In our concept, the specialist trade is the central sales pillar. Our selected and trained specialist dealers can advise you in detail. Above all, however, they offer a promptly available service locally, which we cannot provide within the framework of our manufactory with some production processes planned for the long term. For these reasons we also do not sell directly to the customer at the factory.
A lot works with a lot – but not everything is compatible with everything. This is obvious with some combinations: a hub gear plus a hub motor in the same rear wheel is not possible. The easiest way to choose your specifications: Enter your whishes in our online configurator – we’ve programmed it with all possible combinations, compatibility, and descriptions on our component choices. For detailed advice on choosing the best option for your desired application, please contact your specialist dealer.
System weight means the weight of rider + luggage + bike (if applicable incl. motor). The payload refers to driver + luggage. In practical terms, this means that if you chose a motor for your bike, you have to subtract its weight from the possible payload. At the maximum payload specified for the Scorpion fs 26 Enduro, we make a distinction: When used as a travel trike on the road, the same requirements apply as for the Scorpion fs 26. If the trike is used off-road, we will take into account the much higher stress there with the reduced permitted payload.
For the rear wheel, HP Velotechnik offers a splash guard designed especially for off-road use. It’s different with the front wheels: The tires optimized for off-road use are so wide that the Trikefenders designed for our road trikes don’t fit. However, it is always possible to fit narrower tires (up to 50 mm / 2″) and then retrofit the Enduro trike with Trikefenders.
The Scorpion fs 26 Enduro is a full-suspension action trike designed for use in rough terrain. Extreme sports activities such as freeride or downhill MTBs are not possible; jumping is expressly not permitted. Also, the structural design limits the range of applications. You must always take into account the width of the vehicle (83 cm / 33″ at the front wheels) and the ground clearance (12 cm / 5″ statically compressed). However, you can ride many flow trails in bike parks comfortably.
